GaN PD 100W Multi-Functional Charging Module, It can support power supply for up to 6 devices simultaneously.
Product Description
Input: 100-240V, 50/60Hz, 2.5A Max
Single-Port Output (Max Power)
USB-C1/C2 (High Power):
5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/5A (100W Max)
USB-C3/C4 (Medium Power):
5V/3A, 9V/2A, 12V/1.5A (18W Max)
USB-A1/A2 (Standard Ports):
5V/3A, 9V/2A, 12V/1.5A (18W Max)
Multi-Port Output Modes (Dynamic Power Sharing)
C1 + C2: Shared power 20V/2.5A (50W + 50W or auto-adjusted)
C2 + A1/A2: 20V 1.25A (25W) + 12V 1.5A (18W)
C1 + C2 + C3/C4: 30W + 45W + 18W (Total 93W)
All Ports Active (C1+C2+C3+C4+A1+A2): 38W + 38W + 12W + 12W (Total 100W)
Physical Specifications
Dimensions：102mm × 77.5mm × 16mm (L × W × H)
Weight: Approximately 239g
Certifications: FCC, CE, UKCA
