GaN PD 100W Multi-Functional Charging Module, It can support power supply for up to 4 devices simultaneously.
Product Description
Input: 100-240V, 50/60Hz, 2.5A Max
Single-Port Output (Max Power)
USB-C1/C2 (High Power):
5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/5A (100W Max)
USB-A1/A2 (Standard Ports):
5V/3A, 9V/2A, 12V/1.5A (18W Max)
Multi-Port Output Modes (Dynamic Power Sharing)
USB-C1+C2 output: 65W+30W
USB-C1+A1/A2 output: 65W+18W
USB-C2+A1/A2 output: 65W+18W
USB-C1+C2+C3 output: 30W+45W+18W
USB-C1+C2+A1/A2 output: 45W+30W+18W
USB-A1+A2 output: 5V4.5A
USB-C2+(A1+ A2) output : 65W+22.5W
USB-C1+C2+(A1+A2) output : 45W+30W+22.5W
Physical Specifications
Dimensions：85mm × 85mm × 27mm (L × W × H)
Weight: Approximately 239g
Certifications: CB, CCC, ETL, PSE, FCC, CE, UKCA, SAA, BSMI, ERP
